Automatic tyre changer G5440V.22G - Ravaglioli

Reserved Area

Automatic tyre changer G5440I.22U

Automatic tyre changer G5440V.22G

Mounting head and mounting lever, incl. tire inflator, 2 speeds (max. 14 rpm), passenger car, clamping capacity 10 – 24″, max. rim width 13″ (max. wheel width 330 mm), RAL 7016

MPN: RAV.G5440.206145
GTIN (EAN): 5063084206145
Category:
Tags: , ,
Request Information

Share on:

dashicons-media-document

Description

  • Tilting vertical arm
  • Operating arm with pneumatic locking
  • Air operated bead breaker
  • Oversized body
  • Extractable pedal unit
  • Equipped with:
    • Tyre inflator
    • Clamps protection package
    • Tool protection
    • Bead lever
    • Plastic brush

Media

Similar Products

Accessories

Tech Data

FeaturesAutomatic tyre changer G5440V.22GAutomatic tyre changer G5440V.22GTyre changer G7441IV.22Tyre changer G7441IV.22Tyre changer G7441V.22Tyre changer G7441V.22Automatic tyre changer G5440.22Automatic tyre changer G5440.22Automatic tyre changer G5440.22MAutomatic tyre changer G5440.22M
Mounting head designsemi-automaticautomaticautomaticsemi-automaticsemi-automatic
Mounting arm designmoveablemoveablemoveablemoveablemoveable
Mounting column designtiltabletiltabletiltabletiltabletiltable
TeqLinknot possiblenot possiblenot possiblenot possiblenot possible
asanetworknot possible——not possiblenot possible
Clamping device designClamping plateClamping plateClamping plateClamping plateClamping plate
Min. clamping capacity10″10″10″10″10″
Max. clamping capacity24″22″22″24″24″
Max. rim width13″14,1″14,1″13″13″
Tire type passenger carRun-FlatRun-FlatRun-FlatRun-FlatRun-Flat
Wheel width max.330mm——330mm330mm
Max. wheel diameter1000mm1050mm1050mm1000mm1000mm
Automatic bead-breaking movementNoNoNoNoNo
Bead breaker force12kN10,7kN10,7kN12kN12kN
Number of mounting speeds22211
Rotation speed7 / 14rpm6,5 / 13rpm6,5 / 13rpm7 / 14rpm7 / 14rpm
Max. torque1200Nm1200Nm1200Nm1200Nm1200Nm
Driving power0,8 / 1,1kW0,8 / 1,1kW0,8 / 1,1kW0,55kW0,75kW
Power supply380 V | 50 Hz230/400 V | 50 – 60 Hz230/400 V | 50 – 60 Hz380 V | 50 Hz230 V | 50 Hz
Phases33331
Air flow8bar——8bar8bar
Max. air supply10bar10bar10bar10bar10bar
Width1110mm1304mm1304mm1110mm1110mm
Depth1650mm1449mm1449mm1650mm1650mm
Height1850mm1950mm1950mm1850mm1850mm
Weight233kg234kg214kg233kg233kg
