Tyre changer Karacter.TLX Pro

Professional, with mounting lever and patented plastic mounting head, passenger car, rim diameter 10 – 26″ | Red (RAL 3002)

Category:
Tags:

Share on:

Description

Professional central locking car and light truck tyre changer, with patented plastic mounting head. Ergonomic and fast, thanks to the combination of roller bead breackers and side bead breaker. Suitable for every kind of tyre combination.

  • Equipped with plastic tool and 2 Pneumatic plastic bead breaker rollers for a powerful and easy working process
  • Plastic mounting head: Unlike conventional tools made of metal, the plastic tool allows you to work close to the rim, making it easier to bring the upper bead over the rim flange.
  • Extra-grip clamping device. Three adjustable working heights.
  • Side shovel
  • The position of the disks permit a leverless demounting of the second bead
  • Matching possible without demounting of the tyre
  • Self regulating speed thanks to the inverter technology that adjusts the turns per minute to the required effort (TPM 0-14)
  • Synchronized positioning of the 2 bead breaker disks and separate positioning of the mounting tool
  • Disk advance button for correct and safe bead breaking without damaging the tyre side wall and the pressure sensor
  • Synthetic tool
  • Clamping of revers rims possible without extra required optional
  • Adjustable height of the chucking table
  • WDK-approved

Additional information

Mounting head design

with tire lever

Mounting arm design

swiveling

Mounting column design

rigid

Colour

3002RAL

Workshop-Net

not possible

Clamping device design

central

Min. clamping capacity

10"

Max. clamping capacity

26"

Max. rim width

15"

Min. rim diameter

10"

Max. rim diameter

26"

Tire type passenger car

Run-Flat

Max. wheel diameter

1168mm

Bead breaker force

12kN

Rotation speed

0 – 14rpm

Max. torque

1177Nm

Power inverter motor

1,5kW

Driving power

0,75kW

Power supply

200/265 V, 50 – 60 Hz

Phases

1

Air supply

8bar

Max. air supply

10bar

Width

1360mm

Depth

1800mm

Height

1814mm

Weight

320kg
