Additional information
| Mounting head design | without tire lever |
|---|---|
| Mounting arm design | swiveling |
| Mounting column design | rigid |
| Colour | 3002RAL |
| TeqLink | not possible |
| Workshop-Net | not possible |
| Clamping device design | central |
| Min. clamping capacity | 10" |
| Max. clamping capacity | 26" |
| Max. rim width | 15" |
| Min. rim diameter | 10" |
| Max. rim diameter | 26" |
| Tire type passenger car | Run-Flat |
| Max. wheel width | 380mm |
| Max. wheel diameter | 1168mm |
| Automatic bead-breaking movement | Yes |
| Bead breaker force | 12kN |
| Rotation speed | 0 – 14rpm |
| Max. torque | 1200Nm |
| Power inverter motor | 1,5kW |
| Driving power | 0,75kW |
| Power supply | 200 – 240 V, 50 – 60 Hz |
| Phases | 1 |
| Air supply | 8bar |
| Max. air supply | 10bar |
| Width | 1572mm |
| Depth | 1620mm |
| Height | 1705mm |
| Weight | 465kg |
