Description
- Leverless operation with double tool (patented)
- TOP tubeless tire inflator device: Powerful tubeless tyre inflation system suitable for any rim diameters – complete with a safety device to protect the operator
loading
Leverless – with patented double tool, automatic, incl. 22″ TFT display and tubeless tyre inflation device, passenger car, rim diameter 12 – 30″, max. rim width 15″ | Red (RAL 3002) | for all tyre types with max. wheel diameter 54″ (1370 mm)
| Mounting head design | without tire lever |
|---|---|
| Mounting arm design | swiveling |
| Mounting column design | rigid |
| Colour | 3002RAL |
| TeqLink | not possible |
| Workshop-Net | not possible |
| Clamping device design | central |
| Min. clamping capacity | 14" |
| Max. clamping capacity | 34" |
| Min. inner clamping range | 10" |
| Max. inner clamping range | 30" |
| Min. outer clamping range | 12" |
| Max. outer clamping range | 32" |
| Max. rim width | 15" |
| Min. rim diameter | 12" |
| Max. rim diameter | 30" |
| Tire type passenger car | Run-Flat |
| Max. wheel width | 380mm |
| Max. wheel diameter | 1370mm |
| Max. wheel weight | 80kg |
| Automatic bead-breaking movement | Yes |
| Bead breaker force | 12kN |
| Rotation speed | 0 / 18rpm |
| Max. torque | 1200Nm |
| Power inverter motor | 1,5kW |
| Driving power | 0,8 / 1,1kW |
| Power supply | 200/265 V, 50 – 60 Hz |
| Phases | 3 |
| Fuse protection | 16A slow-blow |
| Air supply | 8bar |
| Max. air supply | 10bar |
| Width | 1590mm |
| Depth | 1915mm |
| Height | 1880mm |
| Weight | 640kg |
