Backlit LCD graphic display (132 x 40 mm), automatic cycle, cones for trucks (Ø 202 – 221 mm, 281 mm), with adapter and handwheel nut, wheel lift 200 kg, truck, rim diameter 10 – 26″ (manually adjustable up to 30″)
Guided balancing procedure – Interactive inputs with multifunction keys: the functions related to each key vary according to use and are identified on the display by graphic icons for immediate understanding.
22″ full HD LCD monitor, industrial PC, automatic cycle, cones for trucks (Ø 202 – 221 mm, 281 mm), with…
Interactive LCD Display, passenger car, rim diameter 10 – 26″, RAL 5005
3D, 22″ LCD monitor, passenger car, rim diameter 10 – 26″, max. wheel capacity 43, RAL 5005
3D, 22″ LCD monitor, passenger car, rim diameter 10 – 26″, max. wheel capacity 43, RAL 5005
Stand flange for truck rims having 6 holes – 3 x 170, 186, 205, 222, 245 mm
Stand flange for truck rims having 8 holes – 4 x 275, 285 mm
Stand flange for truck rims having 10 holes – 5x 225, 286, 335 mm
Universal flange with stands
For passenger car, inclusive protection cup | Ø 44 – 112 mm | 1 set / 3 pieces
Complete with shaft, 2 cones, 6 spacers, centering nut and2 bushes | GAR181N or GAR354 required
Centering bush for BMW | option for universal flange GAR181N or GAR191N
Centering bush | option for universal flange GAR181N or GAR191N
Centering bush | option for universal flange GAR181N or GAR1
Centering bush | option for universal flange GAR181N or GAR191N
Centering bush | option for universal flange GAR181N or GAR191N
Centering bushes | option for universal flange GAR181N or GAR191N
Centering bushes for Suzuki GSX R | option for universal flange GAR181N or GAR191N | 1 set / 6 pieces
Stand flange for wheels
Stand flange for wheels
For motorcycles | with shaft, Ø 14 mm, and accessories | GAR181A1 required
For Renault | Ø 60 / 66 mm | 1 set / 2 pieces
Accessory for wheel balancers for commercial vehicles
Accessory for wheel balancers for commercial vehicles
| Features |  Wheel balancer GTL2.120NRC | Wheel balancer GTL4.140RC | Electronic wheel balancer with microprocessor G2.124NR | Electronic wheel balancer with microprocessor G3.150S | Electronic wheel balancer with microprocessor G3.150 |
|---|---|---|---|---|---|
| Wheel data recording | manually | semi-automatic | semi-automatic | semi-automatic | semi-automatic |
| Tread depth measurement | not possible | not possible | not possible | not possible | not possible |
| TeqLink | not possible | not possible | not possible | not possible | not possible |
| asanetwork | not possible | not possible | not possible | not possible | not possible |
| Measuring speed | < 100rpm | < 100rpm | < 100rpm | < 100rpm | < 100rpm |
| Measuring speed truck | 80rpm | 80rpm | — | — | — |
| Measuring time | 6s | 6s | 6s | 6s | 6s |
| Balancing accuracy +/- | 1g | 1g | 1g | 1g | 1g |
| Balancing accuracy truck +/- | 10g | 10g | — | — | — |
| Display | LCD, backlit | LCD | LCD | LCD | LCD |
| Min. rim width | 1,5″ | 1,5″ | 1,5″ | 1,5″ | 1,5″ |
| Max. rim width | 20″ | 20″ | 22″ | 22″ | 22″ |
| Rim diameter min. | 10″ | 10″ | 10″ | 10″ | 10″ |
| Rim diameter max. | 30″ | 30″ | 26″ | 26″ | 26″ |
| Max. wheel diameter | 1300mm | 1300mm | 1020mm | 1090mm | 1090mm |
| Wheel weight max. | 200kg | 200kg | 70kg | 70kg | 70kg |
| Power supply | 230 V | 50 – 60 Hz | 230 V | 50 – 60 Hz | 220 – 240 V | 50 – 60 Hz | 220 – 240 V | 50 – 60 Hz | 220 – 240 V | 50 – 60 Hz |
| Phases | 1 | 1 | 1 | 1 | 1 |
| Width | 1920mm | 2070mm | 1212mm | 1256mm | 1211mm |
| Depth | 1100mm | 1130mm | 1110mm | 953mm | 898mm |
| Height | 1800mm | 1890mm | 1700mm | 1695mm | 1695mm |
| Weight | 175kg | 220kg | 125kg | 145kg | 140kg |
