Scissor lift RAV650N.5.55ISI

5.0 t, electrohydraulic, platform length 5500 mm, with safety latch, play detector, wheel-free jack and wheel alignment, inground

MPN: RAV.650N5.193902
Category:
Tags: , ,

Share on:

dashicons-media-document

Description

The new lift geometry simplifies the flush mounting pit construction. Lift with big platforms, structured and designed for maximum stability also when loaded with large vehicles.

  • Very versatile: the same lift can be flush or floor mounted
  • Easy installation: easy setting up of pit
  • Wide ranging applications: suitable for different operations on various types of vehicle
  • Open flush mounting for turntables: Edge-free platforms that allow the turntables to be positioned over the entire surface of the platform width – Ideal when working on vehicles with narrow track
  • Optimal sliding of jacking beam: Preinstalled galvanised guide on the inner side of the platform, which allows fast and smooth sliding of the jacking beam
  • Alignment lift with built in 8+4 movement play detector (8 movement play detector 2014/45EU compliant): Platforms for total alignment with front seats for turntables, rear rocking surfaces and play detector
  • Plate with embossed surface to prevent plate-wheel sliding
  • Play detector torch: Led technology, Light weight, Ergonomic control
  • Large wheel stop for high working safety
  • Integrated wheel free lift with levelling system to ensure a completely flat working surface
  • Pre-drilled platform for Ravaglioli 3D wheel alignment measuring heads brackets housing
  • Greater lifting height
  • The hydraulic synchronisation of the platform movements is independent of the load distribution, and is guaranteed by a patented hydraulic synchronisation device
  • All pivoting points are equipped with maintenance free self lubricating bushings
  • Base plates with levelling system for an easy installation
  • Mechanical locking device with automatic engagement and pneumatic release, ensuring maximum safety when lift is in parking position
  • The new lift geometry simplifies the flush mounting pit construction
