Automatic, 2 speeds (max. 13 rpm), passenger car, rim diameter 10 – 24,5″, max. rim width 381 mm | Blue (RAL 5005)
Automatic, 2 speeds (max. 13 rpm), passenger car, rim diameter 10 – 24,5″, max. rim width 381 mm | Blue…
Automatic, 2 speeds (max. 13 rpm), passenger car, rim diameter 10 – 24,5″, max. rim width 381 mm | Blue…
Automatic, 2 speeds (max. 13 rpm), passenger car, rim diameter 10 – 24,5″, max. rim width 381 mm | Blue…
Automatic, max. speed 17,3 rpm, passenger car, rim diameter 10 – 24,5″, max. rim width 381 mm | Blue (RAL…
Swing series, with bike chucking table, max. speed 7,3 rpm, motorcycle, clamping capacity 6 – 24″, max. rim width 12″…
Mounting head and mounting lever, self-centring tulip chuck, max. speed 15 rpm, passenger car, clamping capacity 12 – 24″, max.…
Mounting head and mounting lever, incl. tire inflator, max. speed 7/14 rpm, passenger car, clamping capacity 10 – 24″, max.…
Mounting head and mounting lever, incl. tire inflator, max. speed 7/14 rpm, passenger car, clamping capacity 10 – 24″, max.…
Included in WDK kit
For all machines without tool (plastic or steel) quick coupling
For all models with G800A70 – G800A72 – G800A75
Pneumatic device for bead pushing-raising with rotating arm
PLUS83 with WDK bead pressure device
Accessory for tyre changers
Accessory for tyre changers | No optional hexagonal arm!
To be used with G800A51
To be used with G800A49 | necessary G800A119 for PLUS83H (WDK configuration)
G800A70 reduces max working range by 2″
For all models with quick coupling | with wheel hub for quick coupling
For all models with quick coupling | equipped with quick coupling device
For models with quick coupling device | with wheel hub for swinging quick coupling
For all models with quick coupling
For all models with quick coupling G800A70
No quick change of tool head | for all models | complete with attachment to be connected directly to the…
Alloy wheels protections | 10 sets / 40 pieces
Tool protection package for alloy wheels | 1 set / 2 pieces
Tool protection package for alloy wheels | 10 sets / 20 pieces
Tool protection package for alloy wheels | for models with tool | 10 sets / 20 pieces
ALU protection for side bead breaker | 1 piece
ALU protection for side bead breaker | 5 pieces
Bead protection for “Run Flat” tyres | Included in WDK kit | 1 piece
Tool head press-in protections for alloy wheels | 10 sets / 20 pieces
Tyre inflation device for tyre changers
Extend the clamping range by +5″ from outside
For reducing clamping capacity to 8″ wheel diameter | 800A99, G800A107 necessary
Included in WDK kit | 1 set / 50 pieces
Pneumatic device for bead pushing-raising with rotating arm
Alloy wheels protections | 1 set / 4 pieces
Tool head press-in protections for alloy wheels | 1 set / 2 pieces
Renewable | for tyre changers | 1 set / 8 pieces
| Features |  Tyre changer G7441.22 | Tyre changer G7441V.22PLUS | Tyre changer G7441V.22 | Tyre changer G7441IV.22 | Tyre changer G7441.20 | Motorcycle tyre changer G7240.BIKE | Automatic tyre changer G1001.24ELX | Automatic tyre changer G5440.22 | Automatic tyre changer G5440.22M |
|---|---|---|---|---|---|---|---|---|---|
| Mounting head design | automatic | automatic | automatic | automatic | automatic | semi-automatic | with tire lever | semi-automatic | semi-automatic |
| Mounting arm design | moveable | moveable | moveable | moveable | moveable | swiveling | moveable | moveable | moveable |
| Mounting column design | tiltable | tiltable | tiltable | tiltable | tiltable | rigid | rigid | tiltable | tiltable |
| Colour | 5005RAL | 5005RAL | 5005RAL | 5005RAL | 5005RAL | — | — | — | — |
| TeqLink | not possible | not possible | not possible | not possible | not possible | not possible | not possible | not possible | not possible |
| Workshop-Net | not possible | not possible | not possible | not possible | not possible | — | — | — | — |
| Clamping device design | Clamping plate | Clamping plate | Clamping plate | Clamping plate | Clamping plate | Clamping plate | central | Clamping plate | Clamping plate |
| Min. clamping capacity | 10″ | 10″ | 10″ | 10″ | 10″ | 6″ | 12″ | 10″ | 10″ |
| Max. clamping capacity | 22″ | 22″ | 22″ | 22″ | 22″ | 24″ | 24″ | 24″ | 24″ |
| Min. inner clamping range | 12″ | 12″ | 12″ | 12″ | 12″ | — | — | — | — |
| Max. inner clamping range | 24,5″ | 24,5″ | 24,5″ | 24,5″ | 24,5″ | — | — | — | — |
| Min. outer clamping range | 10″ | 10″ | 10″ | 10″ | 10″ | — | — | — | — |
| Max. outer clamping range | 22″ | 22″ | 22″ | 22″ | 22″ | — | — | — | — |
| Max. rim width | 14,1″ | 14,1″ | 14,1″ | 14,1″ | 14,1″ | 12″ | 15″ | 13″ | 13″ |
| Min. rim diameter | 10″ | 10″ | 10″ | 10″ | 10″ | — | — | — | — |
| Max. rim diameter | 24,5″ | 24,5″ | 24,5″ | 24,5″ | 24,5″ | — | — | — | — |
| Tire type passenger car | Run-Flat | Run-Flat | Run-Flat | Run-Flat | Run-Flat | Run-Flat | Run-Flat | Run-Flat | Run-Flat |
| Max. wheel width | 381mm | 381mm | 381mm | 381mm | 381mm | — | — | — | — |
| Max. wheel diameter | 1050mm | 1050mm | 1050mm | 1050mm | 1050mm | 990mm | 1200mm | 1000mm | 1000mm |
| Max. wheel weight | 80kg | 80kg | 80kg | 80kg | 80kg | — | — | — | — |
| Min. working range of the mounting head | 8″ | 8″ | 8″ | 8″ | 8″ | 8″ | — | — | — |
| Max. working range of the mounting head | 24″ | 24″ | 24″ | 24″ | 24″ | 24″ | — | — | — |
| Automatic bead-breaking movement | No | No | No | No | No | No | No | No | No |
| Bead breaker force | 10,7kN | 10,7kN | 10,7kN | 10,7kN | 10,7kN | 10,7kN | 30kN | 12kN | 12kN |
| Number of mounting speeds | 2 | 2 | 2 | 2 | 1 | 1 | 1 | 1 | 1 |
| Rotation speed | 6,5 / 13rpm | 6,5 / 13rpm | 6,5 / 13rpm | 6,5 / 13rpm | 7,3rpm | 7,3rpm | 15rpm | 7 / 14rpm | 7 / 14rpm |
| Max. torque | 1200Nm | 1200Nm | 1200Nm | 1200Nm | 1200Nm | 1200Nm | — | 1200Nm | 1200Nm |
| Power inverter motor | 1,5kW | 1,5kW | 1,5kW | 1,5kW | 1,5kW | 1,5kW | 1,5kW | — | — |
| Driving power | 0,8 / 1,1kW | 0,8 / 1,1kW | 0,8 / 1,1kW | 0,8 / 1,1kW | 0,75kW | 0,75kW | 0,75kW | 0,55kW | 0,75kW |
| Power supply | 230/400 V | 50 – 60 Hz | 230/400 V | 50 – 60 Hz | 230/400 V | 50 – 60 Hz | 230/400 V | 50 – 60 Hz | 400 V | 50 Hz | 400 V | 50 Hz | 200/265 V | 50 – 60 Hz | 380 V | 50 Hz | 230 V | 50 Hz |
| Phases | 3 | 3 | 3 | 3 | 3 | 3 | 1 | 3 | 1 |
| Fuse protection | 16A slow-blow | 16A slow-blow | 16A slow-blow | 16A slow-blow | 16A slow-blow | 16A slow-blow | 16A slow-blow | — | — |
| Air supply | 8bar | 8bar | 8bar | 8bar | 8bar | — | — | — | — |
| Max. air supply | 10bar | 10bar | 10bar | 10bar | 10bar | 10bar | — | 10bar | 10bar |
| Width | 1304mm | 1596mm | 1304mm | 1304mm | 1280mm | 1252mm | 1003mm | 1110mm | 1110mm |
| Weight | 214kg | 244kg | 214kg | 234kg | 202kg | 180kg | 208kg | 233kg | 233kg |
| Depth | 1449mm | 1823mm | 1449mm | 1449mm | 1421mm | 1073mm | 1186mm | 1650mm | 1650mm |
| Height | 1950mm | 1999mm | 1950mm | 1950mm | 1950mm | 1834mm | 1606mm | 1850mm | 1850mm |
