3.5 t, electrohydraulic, symmetrical, supporting arms 2 x 2-piece
Lift for luxury sport cars
For Fiat Ducato, Peugeot Boxer and Citroën Jumper | for quick drop-in of the K arms, Ø 45 mm |…
For Fiat Ducato, Peugeot Boxer and Citroën Jumper | for quick drop-in of the K arms, Ø 45 mm |…
1 set / 2 pieces
1 set / 2 pieces
For Fiat Ducato, Peugeot Boxer and Citroën Jumper | bushing Ø 45 mm | 1 set / 4 pieces
Holding set, adjustable – 2 x rod-shaped supports, 2 x V-shaped supports | bushing Ø 45 mm | needed spacers…
For all lifts with 3-phase power supply
200 mm
Ramps for extra low clearance vehicles
Supports for 2-post lifts | 1 set / 4 pieces
Set of pad extensions for 2-post lifts | 1 set / 4 pieces
| Features |  2-Post lift KPH370.42LLK |
|---|---|
| Number of columns | 2 |
| Mode of drive | electrohydraulic |
| Control | electric |
| Type of installation | floor mounted |
| Rated load capacity | 3500kg |
| Max. lifting height | 2006mm |
| Lifting time | 34s |
| Min. plate height | 75mm |
| Max. plate heigh | 135mm |
| Clear span between | 2922mm |
| Column height | 4162mm |
| Drive-through width | 2615mm |
| Required ceiling height | 4260mm |
| Surface coating | Powder coated |
| Arm layout | symmetrical |
| Telescopic front arms | 2-fold |
| Telescopic rear arms | 2-fold |
| Min. front arm length | 802mm |
| Max. front arm length | 1262mm |
| Min. rear arm length | 802mm |
| Max. rear arm length | 1262mm |
| Driving power | 3 x 2,6kW |
| Power supply | 230/400 V | 50 Hz |
| Width | 3658mm |
| Height | 4162mm |
| Weight | 750kg |
